Features
- Larger Hopper Capacity (35lbs Total)
- Pellet Dump for Easy Pellet Removal!
- Hopper Baffling System (Directs pellets into auger more easily)
- The controller can be mounted on the left or right side of the hopper assembly
- USA Made PID Algorithm
- 301 Stainless Steel Burnpot
- 36,000 BTUs
- PID controller set in 5 degree increments
- Temp range: 160°F-450°F
- Heavy Duty .52 Amp Auger Motor
- Upgraded 9-hole burnpot; creates a more efficient burn
- Combustion fan facilitates a natural convection throughout the grill area
- Smoke Setting & Grill Setting
- Improved Hot Rod Design
- 100% Digitally Controlled
- Easily Mountable
- 1-Year Warranty
- Requires 110v outlet; ±10%
U.S.A Made Hopper Features:
- Redesigned stainless burn pot; pellets drop into the fire which prevents burn back
- Heavy duty welds for custom smoker applications. Perfect for trailer smoker and more
- Larger hole for hot rod to prevent over heating
- Large 35# hopper capacity
- Heavier 15 gauge construction
- Powder coated hopper with high temp paint on auger arm
- Right or left hand controller mounting
- Pellet pro PID controller with low smoke function
- Heavy duty 2 rpm auger motor
- Heavy duty 3200 rpm fan motor
- Pellet removal drop
- Made, Assembled and 100% inspected in the USA by Smoke Daddy Inc
Patriot Hopper Assembly Includes:
- Extra Long 5ft long RTD Probe
- 4ft Meat Probe
- Pre-Drilled leg holes** NEW
- Hopper w/ mounting bolts
- Complete Instructions & Mounting Template
- Info and customer submitted ideas customer submitted ideas on custom uses for the Pellet Pro hopper assembly
- Operating Voltage: AC 110V ±10%, 60Hz
Pellet Pro® PID Technology
PID Description Overview
Proportional-Integral-Derivative (PID) control is the most common control algorithm used in industry and has been universally accepted in industrial control. The popularity of PID controllers can be attributed partly to their robust performance in a wide range of operating conditions and partly to their functional simplicity, which allows engineers to operate them in a simple, straightforward manner.
As the name suggests, PID algorithm consists of three basic coefficients; proportional, integral and derivative which are varied to get optimal response. Closed loop systems, the theory of classical PID and the effects of tuning a closed loop control system are discussed in this paper.
If you would like to see the full article click here
http://www.ni.com/white-paper/3782/en/
DO NOT BE FOOLED BY FAKE PID CONTROLLERS!
These are NOT PID Controllers:
*New* Upgraded Sportsman Algorithm
With our newly reengineered PID algorithm named the “Sportsman Program,” you are now able to set the temperature as low as 100 degrees F for smoking at lower temperatures with a pellet smoker. Perfect for smoking jerky, sausage, fish, or anything else that doesn’t require high temperatures to smoke.
*PLEASE NOTE* Since the hopper assembly needs to maintain a fire in the burnpot at all times, you may need to increase the ventilation by cracking open the grill/smoker door. This will allow the heat to escape properly resulting in lower temperatures.
Manuals and Diagrams
Hopper Assembly Manual
Hopper Assembly Dimensional Diagram
Attaching a Heat Diffuser
Application Cutting Template
Custom 3" Heat Diffuser Risers
For custom smokers, we offer 3″ Risers that allow the Heat Diffuser to sit 3″ above the burnpot.
This will allow adequate space for the heat to disperse evenly throughout the smoker.
Made from high quality 10ga steel.
Disclaimer
The hopper assembly is used by us for custom applications and some modifications may be required. Our hopper assemblies function as described, although we cannot guarantee that it will work with your application. Smoke Daddy Inc. is not liable for any damage caused by the hopper assembly to or in applications using materials or modifications not recommended to be used with the hopper assembly. Smoke Daddy Inc. offers a 30-day money back guarantee where a full refund will be applied once product is received back in un-used condition. Smoke Daddy Inc. will replace any factory defects within 1 year of purchase. Any misuse or modifications made to the hopper assembly will void all warranties. Therefore, this product is being sold subject to the following:
“This hopper assembly is provided ‘as is’ and with the limited warranty as stated above. Smoke Daddy makes no further guaranties or warranties of any kind, either expressed or implied, including but not limited to warranties for a particular purpose, warranty of merchantability or of non-infringement of any rights of third parties.”
For questions on custom applications, please call us at 847-336-1329.
Hopper Cover
Now you can better protect your hopper assembly from the elements!
Made from high quality fabric, the cover is plastic lined which will prevent the pellets from absorbing moisture in addition to protecting the controller.
This cover is designed to fit on our 35lb capacity hopper assemblies.
It will fit on smaller capacity hoppers, although it will not be a snug fit.
Dimensions: 12″ x 14″ x 20″
Also includes an adjustable bottom strap!
